LIST CODE 2

1. P/N: 007297  Magtrol

Model: AHB-3.3 Magtrol

BRAKE, AIR COOLED, 24V

Rated torque 3.3 Nm

Max braking power 2,000 W

Max speed 25,000 rpm

24 Volt Coil

This unit requires 620 KPa (90 psi) @ 20 SCFM for proper cooling

2. Model:  004661  Magtrol

Item: HB-450-1 Magtrol

Hysteresis brake HB-450-1 Min. torque at rated current

450Oz.in Max. speed 8’000min-1 Power ratings continuous

160W Power ratings intermittent 670W Power supply

93.6VDC

3. Model: 311-101-051-101 Magtrol

CALIBRATION ARM

Calibration arm for WB/PB 43  (need 2 per dyno!)

4. Model: 312-101-000-051

Item: 1WB65

Eddy currrent dynamometer

including speed probe OS 123

Rated torque   10Nm at  5730min-1

Maximum braking power   6kW

Maximum speed 30000min-1

5. Model: 234-411-000-111 Magtrol

Item: DES 411/111  Kit for Dyno 65, 115 & 1WB15

Kit dynamometer excitation supply for series 65, 115 and 15 dynamometer, in aluminium housing, with 5m cable between DES411 and DSP6001/7000 and 1.5m cable between DES411 and dyno

6. Model: 234-401-000-222 Magtrol

Item: TSC 401/222  FOR DYNO 65, 115 & 15

Torque-Speed Conditioner for 65, 115 and 15 series

dynamometers suitable for DSP6001/7000 with 2x 1.5m

cables between TSC401 and dynamometer

7. Model: 88M372-0500 Magtrol

Item: TORQUE-SPEED CABLE 14M/15F  (DSP TO TSC/DYNO)  5m

Torque/speed cable 14-pin male – 15-pin female for

dynamometers / TSC with DSP6001 / 700x electronic, length 5m

8. SPECIALITEM

Item CW-ENR.004 FOR 1WB65 Magtrol

Chiller water cooling system

Cooling power 6.9kW

Pump pressure 2.7bar

Water flow rate 17l/min

Plastic water tank 25liters

Dimensions L=600 W=725 H=1060mm

Power supply 230VAC 50Hz

Electrical power consumption 2.1kW

Noise level at 10m 51.6dB (A)

With IN / OUT external stop valves and connections

With control valve and manometer

With air flush inlet

Electrical connector and water hoses not included

9. Model: 422-214-000-013 Magtrol

Item: LE 214/013  50kN Magtrol

Strain gauge load measuring pin, execution

with integrated 2-wire signal amplifier

(4-20mA). Nominal load 50kN, axial connector

10. Model: 422-218-000-013 Magtrol

Item: LE 218/013  500kN Magtrol

Strain gauge load measuring pin, execution

with integrated 2-wire signal amplifier

(4-20mA). Nominal load 500kN, axial connector

11. Model: 122-216/011/004 Magtrol

Item: LB 216-011/004  100kN, 20m Magtrol

Strain gauge load measuring pin in standard version.

Nominal load 100kN integral cable 20m, PG radial

12. Model: 311-201-000-051 Magtrol

Item: 2WB43 Magtrol

Eddy currrent dynamometer including speed probe OS 123

Rated torque 3 Nm at 9550min-1 Maximum braking power 3

kW Maximum speed 50000min-1

13. Model: 234-410-000-111 Magtrol

Item: DES 410/111  KIT FOR DYNO 2.7 & 43 Magtrol

Kit dynamometer excitation supply for series 2.7 and 43

dynamometer, in aluminium housing, with 5m cable between

DES410 and DSP6001/7000 and 1.5m cable between

DES410 and dyno

14. Model: 234-401-000-212 Magtrol

Item: TSC 401/212 FOR DYNO 2.7 & 43 Magtrol

Torque-Speed Conditioner for 2.7 and 43 series

dynamometers suitable for DSP6001/7000

With 2x 1.5m cables between TSC401 and dynamometer

15. Model: 88M372-0500 Magtrol

Item: TORQUE-SPEED CABLE 14M/15F  (DSP TO TSC/DYNO)  5m Magtrol

Torque/speed cable 14-pin male – 15-pin female for

dynamometers / TSC with DSP6001 / 700x electronic, length 5m

16. Model: 955-01-01-0618

Item: CW-ENR.002 FOR 2WB43 Magtrol

Chiller water cooling system

Cooling power 3.1kW

Pump pressure 2.7bar

Water flow rate 7.6l/min

Water tank 10 l

Dimensions L=445 W=440 H=806mm

Power supply 1~ 230VAC 50Hz

Electrical power consumption 1.4kW

Noise level at 10m 50.0dB (A)

With IN / OUT external stop valves and connections

With control valve and manometer

With air flush inlet

Electrical connector and water hoses not included

17. Model: 73M044 Magtrol

Item: USB-GPIB-HS+ CARD+2m CABLE  W7-SP1 / W10 Magtrol

GPIB-USB-HS card included 2m cable compatible Windows 7SP1/10

18. Model: 88M047 Magtrol

Item: GPIB CABLE X2   1m Magtrol

GPIB Cable, length 1m

19. Model: 850-016-000-141 Magtrol

Item: DYNO TABLE TAB-43/65/115 RACK 19″ Magtrol

Mobiel table with 19″ rack mount option Base plate 980 x

430 x 50 mm (L x W x H) With 3 T-nut grooves, size 12H8,

gap 125 mm Aluminium frame with wheels Incl. fixing plate

for DES and TSC Dimension 1041 x 503 x 812 mm (L x W x

H) According to drawing 850-016-000V141

20. Model: 204216 Magtrol

Item: FIXTURE ONLY AMF-2 Magtrol

Fixture only AMF-2 for motor max. Ø 150mm used with

dynamometer series HD-700

21. Model: 88M368-0150 – CABLE, D-SUB 15M/D-SUB 15F, 1.5m, SHIELDED  Magtrol

SIGNAL

CABLE, D-SUB 15M TO D-SUB 15F LONG L/T

22. Model: 007726 – HD-810-5C2-0100  Magtrol

DYNAMOMETER, 240 VAC, 60 PPR, SHORT

Rated torque 14.0 Nm (0-5 Vdc output)

New connectors

Short Base Plate

Max braking power 3,500 W

Max speed 12,000 rpm

Blower Cooled

Encoder 60 PPR

23. Model: 007941 – DSP7011  Magtrol

CONTROLLER, 1-CHANNEL (GPIB, USB, 1 I/O)

High-Speed Programmable Dynamometer

Controller, Single Channel, USB Interface,

GPIB Interface, Single I/O Card
