LIST CODE 1

1. Model: 224-212-011 – LMU 212/011 Magtrol

LOAD MONITORING UNIT /2 LEV

Load monitoring unit with 2 sensor input,

2 O/P 4-20 mA and 2 O/P 0-10 V

Power supply 18…32 VDC

2. P/N: 006249

Model:  AHB-12

BRAKE, AIR COOLED, 24V

Rated torque 12 Nm

Max braking power 2,800 W

Max speed 12,000 rpm

24 Volt Coil

This unit requires 620 KPa (90 psi) @ 20 SCFM for proper cooling

3. P/N: 005676 Magtrol

Model:   AHB-1

BRAKE, AIR COOLED, 24V

Rated torque 1.0 Nm

Max braking power 1,200 W

Max speed 25,000 rpm

24 Volt Coil

This unit requires 620 KPa (90 psi) @ 20 SCFM for proper cooling

4. P/N: 007714  Magtrol

Model:   HD-715-5C2-0100

DYNAMOMETER, 240 VAC, 60 PPR, SHORT

Rated torque 6.20 Nm (0-5 Vdc output)

New connectors

Short Base Plate

Max braking power 3,400 W

Max speed 25,000 rpm

Blower Cooled

Encoder 60 PPR

*NOTE: The quotation just quoted DYNAMOMETER only

Please check what controller and cable will this dyno be used with as without them the equipment cannot be uses

5. P/N: 88M370-0500 Magtrol

Model:   CABLE ASSY,M12-4F/CINCH 2M,5m

BRAKE CABLE, M12-4F TO CINCH-2M

*Note: Cable set for use with an existing DSP7000 series controller

6. P/N:  88M372-0500 Magtrol

Model:   CABLE ASSY, D-SUB 15F/14P AMPHENOL, 5m

SIGNAL CABLE, D-SUB 15F TO MICRO-RIBBON-14

*Note: Cable set for use with an existing DSP7000 series controller

7. Model: 843-102-000-011

CTS 102 COGGING TEST SYSTEM 200mNm Magtrol

Cogging Test System

Measuring range: 0 – 200 mNm

Accuracy: 0.05% of rated torque

Speed: 1 – 10 rpm

Shaft height: 100 mm

Mounted on PT-25 base, length 600 mm

With USB interface

Incl. Control and Data Acquisition Software (LabVIEW exe)

8. Model:  424-102-000-211

TS 102/211  0.2Nm 5000PPR

Torque Sensor with smooth shaft

Analog and USB outputs

Rated Torque 0.2 Nm, Accuracy <0.05%

Max Measurable Torque 0.4 Nm

Max speed 1000 rpm

With 5000 Bits Encoder (A, B, Z)

Incl. 3 m. analog and 2 m. USB cables

9. Model:  843-105-000-011

CTS 105 COGGING TEST SYSTEM 2Nm

Cogging Test System

Measuring range: 0 – 2Nm

Accuracy: 0.05% of rated torque

Speed: 1 – 10RPM

Shaft height: 180mm

Mounted on PT-25 base, length 800 mm

With USB interface

Incl. control and data acquisition software (LabVIEW exe)

10. Model:  424-105-000-211

TS 105/211  2Nm 5000PPR Magtrol

Torque Sensor with smooth shaft

Analog and USB outputs

Rated Torque 2 Nm, Accuracy <0.05%

Max Measurable Torque 4 Nm

Max speed 1000 rpm

With 5000 Bits Encoder (A, B, Z)

Incl. 3 m. analog and 2 m. USB cables

11. P/N: 317-101-900-021 Magtrol

Model: 1WB32 Magtrol

EDDY CURRENT SYSTEM, WITH FIXTURE, 0.4 Nm

1WB32 High Speed Eddy Current Dynamometer

Rated torque 0.4  Nm at 11,950 rpm

Power rating:  500 W

Maximum speed 80,000 rpm

With integrated Torque-Speed measurement

With integrated dyno excitation suppy

Mounted on 765mm T-Slots base plate

With AMF-1 motor fixture

with protection guard including closing contact

As per drawing 317-101-000V011

12. P/N: 88M368-0500 Magtrol

CABLE, D-SUB 15M/D-SUB 15F, 5.0m, SHIELDED

SIGNAL CABLE, D-SUB 15M TO D-SUB 15F, SPECIAL

13. P/N: 957-18-25-0301  Magtrol

EXCITATION CABLE L=5m FOR WB 32 + DSP701X

14. P/N: 007941 Magtrol

Model: DSP7011 Magtrol

CONTROLLER, 1-CHANNEL (GPIB, USB, 1 I/O)

High-Speed Programmable Dynamometer

Controller, Single Channel, USB Interface,

GPIB Interface, Single I/O Card

15. P/N: 954-21-11-0126 Magtrol

Model: MIC-5-0039 10H7/10H7 Magtrol

COUPLING, 10mm – 10mm 20K RPM

16. Model: 005617 Magtrol

Item: 5500  SWITCHBOX 3 IN 1 include 2 cables Magtrol

3:1 Manually controlled switchbox including cable set: 1x

Excitation cable P/N 88M070 1.5m 1x Torque/speed cable

P/N 88M007 1.5m

17. Model: LB-450M-1 (90 VDC) Magtrol

SPECIALITEM

Art. Nbr. 005254

Hysteresis brake with hollow shaft Ø 42 mm Torque at

Working current 3.00Nm Maximum speed 2’500min-1

Continuous power max. 160W Short time max. 670W

Supply voltage 90VDC

18. Model: 006071 Magtrol

AHB-3

BRAKE, AIR COOLED, 24V

Rated torque 3.0 Nm

Max braking power 1,800 W

Max speed 20,000 rpm

24 Volt Coil

This unit requires 620 KPa (90 psi) @ 20 SCFM for proper cooling

19. Model: 007710 – HD-710-5C2-0100   Magtrol

DYNAMOMETER, 240 VAC, 60 PPR, SHORT

Rated torque 3.10 Nm (0-5 Vdc output)

New connectors

Short Base Plate

Max braking power 1,500 W

Max speed 25,000 rpm

Blower Cooled

Encoder 60 PPR

240 Vac

20. Model: 88M367-0150 – CABLE,M12-4M/M12-4F,1.5M,SHIELDED  Magtrol

BRAKE CABLE, M12-

4M TO M12-4F
