LISTCODE 2 080726

BIGBIG

1 100% EU Origin

MDEXX Fan Vietnam

Code: 22549673 Cooling Fan for Chiller Systems.

IS-R-05669-4I5-22549673 Cooling Fan for Chiller Systems.

This is a complete fan including housing, not just an insert as requested.

***

External fan designation: IS-R-05669-4I522549673 Cooling Fan for Chiller Systems.

Fan size: 560 mm

Customer material number:

External fan for: 1LE5 40

Fan type: Radial

Special version:

– IP55

– 380V/660V D/Y at 50 Hz

– 440VVD at 60 Hz

– Coolant temperature -30°C to 55°C

Impeller: Steel sheet, epoxy powder coating RAL7032

Housing: Primed according to CI_2

Drawing number: VZF4408-32

Design: according to ERP DVO 327

Motor: IP55 RAL7030

Mounting material: Galvanized

Operating data:

– 50 Hz: Vpkt=1.55 m^3/s Pt=349 Pa PL=1.19kW

– 60 Hz: Vpkt=1.86 m^3/s Pt=481 Pa PL=1.98kW

Technical delivery conditions according to DIN

24166, accuracy class 2

Tolerances for electrical specifications according to DIN EN 60034

Vibrations according to ISO 14694

Balance and vibration category: BV3

Inspection certificate EN 10204-3.1 (German)

(attached to the delivery documents)

1 100% Germany/EU Origin

Marathon/ GNB / Exide Technologies Vietnam

Code: NAXL120070HM0FA

Marathon XL series battery

1 100% US Origin

Allen Bradley/ Vietnam

Model:  20F1ANC456JA0NNNNN

PowerFlex Air Cooled 753 AC Drive

2 100% Mexico Origin

Allen Bradley/ Vietnam

Model:  20-HIM-A6

Allen-Bradley PowerFlex VSD Mount LCD Display and

Programmer

2 100% US Origin

Allen Bradley/ Vietnam

Model:  20-750-2263C-1R2T

PowerFlex 750-Series 24V DC I/O Module

1 100% EU Origin

FLOMEC Vietnam

Type: G2S10IQ9LMA

turbine flow meter

Totaliser, sub-totaliser and flow meter

Material: Stainless steel

Connection: 1″ BSPT

Measuring range: 19–190 l/min

Special features: None

Power supply: 2 x lithium batteries

1 100%  France Origin

Celduc Vietnam

Code: SGT9874300

SOLID STATE RELAYS

ZC THREE PHASE SSR 3X75A/24-660VAC/CTRL 4-30VDC

MOQ (Minimum Order Quantity): 16pc

1 100% Germany Origin

Senseca (GHM/ Honsberg) Vietnam

Order Code: LABO-XF-I025GMQ015VONS

Flow Transmitter/ Switch

Version LABO-XF with signal output

Output signal: urrent output 4 … 20 mA

Nominal diameter: DN 25 – G 1

Connection type: Female thread

Connection material: Brass CW614N nickel-plated

Body material: PPS

Measuring range H2O: 1 … 15 l/min H2O

Seal material: FKM

Reverse flow protection: Without reverse flow protection

Programming: No teaching (not programmable)

1 100% Germany Origin

Microsonic Vietnam

Model:  ews-100/M18/CD Set

ews through-beam sensor

1 100% EU Origin

IMI Maxseal / Norgren Vietnam

Model: Y123AA3H1BS

Ic04S 20B-3/2 Aut 1/2Npt 24Vdc

Maxseal ICO4S 24Vdc direct acting 3/2 stainless steel 1/4 NPT ported valve

2 100% EU Origin

IMI Maxseal / Norgren Vietnam

Model: Y013AA1H1BS

Pneumatic valve, 3/2, 1/4 NPT

1 100% EU Origin

VAHLE Vietnam

Model: 0167066/00

U10/25C-6000PE-A

INSULATED BUSBAR U 10/25 C -6 PE

Conductor system

1 100% EU Origin

VAHLE Vietnam

Model: SA-KDS2/40/04PH-88/15-0,5

168073

KDS 2/40 PH DUAL POWER TAKE-OFF

WITH 0.5 M CONNECTION CABLE

Single conductor

1 100% Italy Origin

MICROELETTRICA SCIENTIFICA Vietnam

MODEL: LTC 250 1P NC V220DC

Contactor

LTC 250, Poles 1NC Single,

Mounting position: Vertical, Plastic arc chute,

Control voltage 220 Vdc, aux contacts type SJ Fast-on 2NO+2NC

1 100% Taiwan Origin

Nitto Seiko  Vietnam

MODEL: RQ3E080B0S2PAX000010R

TAG NO : FQC-01 / FQC-02 / FQC-03 /  FQC-04 /   FQC-05 /  FQC-06

SPECIFICATIONS

FLUID: WATER (@1mPa.s)

FLOW RANGE: 3.5 – 35 M3/H (ACCURACY: +-0.5%)

MAX. TEMP.: 60 DEG C

CONNECTION: 80A JIS 10K RF FLANGE (MAX. PRESSURE: 1.0 MPa)

INDICATION: 7 SEGMENT LCD DISPLAY

OUTPUT: PULSE ALARM, ANALOG OUTPUT (EXPLOSION PROOF ExdII BT4 Gb)

MATERIAL

BODY AND MEASURING CHAMBER: SCS14A / ROTOR: PPS / PACKING: TEFLON

OIL-FREE TREATMENT: WITH

EXTERNAL POWER: WITH

2 100% Taiwan Origin

Nitto Seiko  Vietnam

MODEL: RQ3E025B0S2PAX000010F

TAG NO : FIQ-05 /  FIQ-06

SPECIFICATIONS

FLUID: NH4OH (@1mPa.s)

FLOW RANGE: 0.35 – 3.5 M3/H (ACCURACY: +-0.5%)

MAX. TEMP.: 60 DEG C

CONNECTION: 25A JIS 10K FF FLANGE (MAX. PRESSURE: 1.0 MPa) INDICATION: 7 SEGMENT LCD DISPLAY

OUTPUT: PULSE ALARM, ANALOG OUTPUT (EXPLOSION PROOF ExdII BT4 Gb) MATERIAL

BODY AND MEASURING CHAMBER: SCS14A / ROTOR: PPS / PACKING: TEFLON

OIL-FREE TREATMENT: WITH

EXTERNAL POWER: WITH

3 100% Taiwan Origin

Nitto Seiko  Vietnam

MODEL: RQ3E080B0S2PAX000010R

TAG NO : FIQ-01 /  FIQ-02

SPECIFICATIONS

FLUID: PROCESS (@1mPa.s)

FLOW RANGE: 3.5 – 35 M3/H (ACCURACY: +-0.5%)

MAX. TEMP.: 60 DEG C

CONNECTION: 80A JIS 10K RF FLANGE (MAX. PRESSURE: 1.0 MPa) INDICATION: 7 SEGMENT LCD DISPLAY

OUTPUT: PULSE ALARM, ANALOG OUTPUT (EXPLOSION PROOF ExdII BT4 Gb) MATERIAL

BODY AND MEASURING CHAMBER: SCS14A / ROTOR: PPS / PACKING: TEFLON

OIL-FREE TREATMENT: WITH

EXTERNAL POWER: WITH

4 100% Taiwan Origin

Nitto Seiko  Vietnam

MODEL: NQ10LGLSEF

TAG NO : FIQ-04

SPECIFICATIONS

FLUID: CT (@1mPa.s)

FLOW RANGE: 0.02 – 0.6 M3/H (ACCURACY: +-0.75%)

MAX. TEMP.: 60 DEG C

CONNECTION: 20A JIS 10K RF FLANGE (MAX. PRESSURE: 1.0 MPa) INDICATION: 7 SEGMENT LCD DISPLAY

OUTPUT: PULSE ALARM, ANALOG OUTPUT (EXPLOSION PROOF ExdII BT4 Gb) MATERIAL

BODY AND MEASURING CHAMBER: SCS14 / ROTOR: CARBON

OIL-FREE TREATMENT: WITH

EXTERNAL POWER: WITH

1 100% Japan Origin

SANYO DENKI Vietnam

Model:  109-312

AC Axial Fan 172×51, 200VAC

1 100% Japan Origin

SANYO DENKI Vietnam

Model: 109S472UL-20

AC Axial Fan 120×38, 230VAC, Low speed Sensor

1 100% Germany Origin

Euchner  Vietnam

Article: CMS-R-BZD-05V

Order no.:159518

READ HEAD
