LISTCODE#2#260526

BIGBIG

1 100% Slovakia Origin

SPINEA, s.r.o., Vietnam

Product Model: TS 200-063-TC-P24-0293A

Gearbox

Drawing Number: 0-293 P00 #00-3  / IGS / PDF / DWG / STP

Type Size: TS 200

Ratio: 63

Model: TC-P24-0293

Technical data: according to the data given in drawing and catalogue

Note: Drawing  0-293

1 Recheck Origin

Motion Sensor Vietnam

Model: HN75-35/3.5

Hall Effect, Exd, 5V, FNPT, 5/8-18, 3.5″ Thread,

4.6″ OAL, 3.5′ Pigtaill

Part Specifications:

ATEX and IECEx certified to Ex d

Ex II 2 G

Ex d IIC T6 to T4

LCIE 11 ATEX 3029 X

IECEx LCI 11.0012X

Ambient temperature T6: -40°C <= Ta <= 70°C

Ambient temperature T5: -40°C <= Ta <= 85°C

Ambient temperature T4: -40°C <= Ta <= 100°C

Reference installation instructions for installation considerations.

All instructions provided in English.

1 100% USA Origin

Temposonics/MTS Vietnam

Code: RP5SA0270M01R021A100

Temposonics® R-Series

Note: RPS0270MR021A01 is no longer

<3 jproaut 1    100% TAIWAN Origin

EYC Vietnam  – EYC Viet Nam – EYC-Vietnam

Code: FTS35-2011-02N

Air velocity transmitter remote type

0~20m/s,4-20mA,2M PVC cable,Cable gland

1 100% Korea Origin

Pora Vietnam

Model: PRB-1.2YN

Power brake

<3 jprohq 1 100% US/CHINA Origin

ATO Vietnam  – ATO Viet Nam – ATO-Vietnam

Code: ATO-TQS-S04+LCTR-OA Torque Sensor

Micro Reaction Torque Sensor for Static Torque Load Cell Transmitter is already included in the Output Signal options

1 100% Swiss/ EU Origin

KNF Vietnam

Model: 046404/043433

MICRO DIAPHRAGM GAS PUMPS NMP05KPDC-L 6 V

Chọn 1 trong 2

2.1       100% Swiss/ EU Origin

KNF Vietnam

Model: 046403/046566

MICRO DIAPHRAGM GAS PUMPS NMP05KPDC-S 3V

2.2       100% Swiss/ EU Origin

KNF Vietnam

Model: 046403/046567

MICRO DIAPHRAGM GAS PUMPS NMP05KPDC-S 5V

<3 jpro40 1 100% Italy Origin

WEG Automation Vietnam / Gefran Drive Vietnam    – WEG Automation Viet Nam / Gefran Drive Viet Nam – WEG Automation-Vietnam / Gefran Drive-Vietnam
Code: ADV-2075-KBX-4+SI braking unit

S9O07SI Integrated braking unit – Integrated EMC filter – Integrated DC choke + Safety Card, 7.5kW, 11kW

2 100% Italy Origin

WEG Automation Vietnam / Gefran Drive Vietnam
Code: S526L I/O Interface Converter

EXP-IO-D6A4R1-ADV I/O Interface Converter

I/O expansion – 4 Digital inputs / 2 Digital outputs / 2 Analog inputs / 2 Analog outputs / 2 Relays double contact

1 100% Italy Origin

SIRCA Vietnam

Model: AP03DA0BH2BIS Actuator

1 100% EU/China Origin

Siemens Vietnam

Model:   6ES7414-4HM14-0AB0

SIMATIC S7-400H, CPU

1 100% Germany Origin

IMI Herion Vietnam

Model: 9713545205100000

97105 series Inline solenoid valve, 1/4 NPT, 3/2, NC, solenoid pilot / spring return

1 100% EU Origin

Saia Burgess Controls Vietnam

Model: KOL360H7MRVPN00

Electronic time relay

No. 9600042

1 100% Korea Origin

Kyungjin Blower Vietnam

Code: AC-150B

Description: CROSS FLOW COOLING FANS

208v-230v/50/60hz/1phase

1 100% EU Origin

SEW Vietnam

Replacement Model: SA57/T D16 DRN80M4

Helical-worm gearmotors S..DRN.. (IE3)

*Replacement for SA52/T D16 DT80N4 30.0110790301.0001.00, but with current motor

and gearbox generation.

Please note that the motors may differ in size (length, diameter, terminal box position) and technical data.

Therefore, please check the technical

data and dimension sheets.As same as:

Product data

Speed [r/min]: 1440 / 12 – 61

Total ratio [i]: 29,00 / finite

No. of teeth nom./denominator: 29/1

Output torque [Nm]: 150 / 83

Mounting position: M4B

Term.box.pos.[°] / cable entry: 0 (R) / normal

Oil manufacturer designation: SEW GearOil Base 680 S E1

Lubricant / -volume [l]: CLP 680 Miner.Oil / 1,45

Paint coat: Top coat RAL7031 (blue

gray)

Gear unit: SA57/T

Hollow shaft: 30mm

Design: Hollow shaft

Safety cover: None

Add. feature gen. information: Torque arm with fastening parts

Breather variant: Standard

Delivery state: Breather valve mounted in flange

Screw plug bore dimens. sheet: 27001__97

Gear unit: D16

Ratio range [1: ] : 5

Position remote contr. [°]: 270

Documentation no. A: 19368402

Parts list: 152520793 / 15321386

Motor: DRN80M4

Motor power [kW]: 0,75

Motor frequency [Hz]: 50

Cyclic duration factor S1-S10: S1

Motor voltage [V] / conn. type: 220/380 delta/star

Nominal current [A]: 3,20 / 1,84

cos phi: 0,74

Wiring diagram: R13 / 680010506

Thermal cl.[°C]/Enclosure[IP]: 155(F) / 55

International efficiency class: IE3

Efficiency

at 50/75/100% Pn [%]: 80,7 / 82,9 / 82,9

CE mark: Yes

Fan guard: Metal fan guard

Terminal box: Ter
