1.  Mayr-Type 49A.625.0

EAS-compact rustproof Size 0

Hub short (keyway) bore: 25mm H7

Torque setting: preset

Torque limit for overload 20 to 50 Nm

2.  Mayr-DS Y7110084

Coupling

ROBA-DS Size 16 Type 9110.00010

ART no.: 7047440

Nominal torque 300 Nm

Peak torque 450 Nm

Coupling dynamic balanced G2.5 at 3000 rpm

3.  Mayr-Z7129838 8229619

Brake Mayr ROBA-servostop

Size 120/898.002.00S

Voltage:24v

Braking torque:32NM

According to 8229619

4.  Mayr-EAS-400 Size 4 Type 400.400.0

Torque limiter

Art no.: 0012021-1

Hub bore: Ø30 mm H7

Torque setting: not adjusted

Torque limit for overload 50 to 100 Nm

5.  Mayr-ROBA-ES Size 24, type 940.022.A

Elastomer coupling

Art. no.: 7000355

Hub 1 with keyway, bore: Ø25 mm H7

Hub 2 with keyway, bore: Ø25 mm H7

Elastomeric element red 98Sh-A

Nominal torque: 60 Nm

Max. clutch torque: 120 Nm

6.  Mayr-Element (RED) for ROBA ES 24 – SH98 A

Elastomeric element

7.  Mayr-EAS-400 Size 2 Type 400.605.0

Safety clutch

Mayr Art-No: 8199684-1

Hub bore: 35 mm

fit: H7

keyway: DIN 6885 Bl.1 JS9

adjustment torque: not adjusted

Torque limit for overload 100 to 200 Nm

Adjusting nut for radial adjustment

8.  Mayr-Size 60 Type 381.110.0

ROBA-linearstop pneumatic

Holding force setting: 7300 N

Min. operating pressure: 4,5 bar required for

proper release of brake.

Threaded joint: aligned direction

9.  Mayr-Size 60 Type 891.104.1 S

ROBA-stop M

Mayr Art-No: 8227854-1

Hub bore: Ø30 mmH7

Coil body 24 Vdc

Cable length: 400 mm

Braking torque 100 Nm

with threaded holes in coil carrierspecial design

acc. to our drawing no. E07006274000210

10.  Mayr-Size 6 Type 4043.70400

EAS-dutytorque

Hub bore: Ø110 mm H7

Hub for elastic clutch bore: Ø90 mm H7

Include control component pressure flange

Torque setting: 4350 Nm

Hub (pos.1), overload module with cam ring

(pos.2) and flange hub with claw ring (pos.3)

complete dynamic balanced with balance

quality G2.5 at 1500 rpm.

Torque limit for overload 2800 to 5600 Nm

11.  Mayr-Type 017.000.2

ROBA-switch fast acting rectifier size 10

Overexcitation time: 0.45 s

Input voltage 100 – 250 V AC

Output voltage 45 – 113 V DC

Operation with overexcitation or power

reduction

Max. current loading 2,0 Amp. at <= 45° C

ambient temperature, 1,0 Amp. at max. 70° C

ambient temperature

Protection class IP65 (terminals IP20)

UL and CE marking

12.  Mayr-AS-Sp Size 1 Type 450.115.0

Safety clutch

Hub (cone bushing) bore: 30 mmH7

Cone bushing: stator element side without

counterbore

Limit switch normally closed

Limit torque for overload 25 to 150 Nm

13.  Mayr– Type 899.000.01

ROBA-topstop size 120

Shaft (d x l): 24×50 mmk6

Bore d1: 24 mmF7

Keyway: output-sided

Magnetic coil 24 V

Flange housing (motor-side)

Centering Z1: 110 mmF8

Pitch circle: 130 mm

Bearing flange (output-side)

Centering Z: 110 mmj6

Braking torque 12 Nm

Release monitoring with proximity switch PNP

NO
