1.  Code: M6-4S2HX51-W003

M6C Flameproof Explosion Protected Encoder, ATEX/IECEx Zone 1

Hollow Shaft Bore Size : 4 – 1 inch Hollow Shaft

Mounting : S – Standard End-of-Shaft Mounting

Line Driver : 8 – 5-24V In/Out Protected Line Driver

Left Output : H – High Res.

Right Output : X – No Right Output

Base PPR: 51 – 512 PPR

Marker :  – – No Marker

Connector Options : W – Terminal with Cable Gland

Modifications:  003 – Includes B28390 Torque Arm Kit ”

2.  Code: HS35MYX6FCU1HA00

HS35M Hollow Shaft Magnetic Mill Duty Encoder

Left Output PPR

Y – 1024 PPR

Right Output PPR

X – No Right Output

Line Driver

6 – 5-24v In/Out (7272)

Hollow Shaft Bore Size

F – 1 in. (Native Bore)

Connector Options

C – 10 Pin MS Style with Plug, Avtron/BEI Pin Out

Mounting

U – Universal (Thru & End of Shaft)

Protection

1 – Protective Basket Included

Anti-Rotational Tether

H – A and F Tether Kits

Channels and Modifications

A00 – Standard, No Special Features, All Channels A, A\, B, B\, Z, Z\

HS35MYX6FCU1HA00 Replaces part number RA35MY6FCU1HA00 ”

3.  Code: HS35MYX6CPU1CA00

HS35M Hollow Shaft Magnetic Mill Duty Encoder

Left Output PPR: Y – 1024 PPR

Right Output PPR : X – No Right Output

Line Driver: 6 – 5-28v In/Out (7272)

Hollow Shaft Bore Size: C – 5/8 in. via insert

Connector Options: P – 10 Pin Mini-Epic Style with Plug

Mounting: U – Universal (Thru & End of Shaft)

Protection: 1 – Protective Basket Included Anti-Rotational Tether: C – 0.375 16 T-Bolt Fan Cover Tether

Channels and Modifications: A00 – Standard, No Special Features, All Channels A, A\, B, B\, Z, Z\ ”

4.  Code: AV56A1KFX6YXGP50

Replaces part number AV56A1TFX1YXG007

THIN-LINE™ III Heavy Mill Duty Magnetic Modular Encoder 4.5″” C-Face Mount

Housing Type: 1 – Single Output

Rotor Bore Size: KF – 1 1/8″” Thru-Shaft Cam Screw Rotor for Wolong/GE Pitch Motor

Cover Style : X – No Cover Plate

Line Driver: 6 – 5-24v in, 5-24v out (7272) recommended for single-ended wiring (A,B,Z, no A/,B/,Z/)

Left Output PPR: Y – 1024 PPR

Right Output PPR: X – No Right Output, Single Output Only

Connector Options: G – Ind’l w/Northstar Pinout (EPIC Style connector), w/mating plug, LED diagnostics

Modifications: P50 – Special options for GE Motor, upgraded model including diagnostic LED & cam screw rotor and super magnetic shielding ”

5.  Code: M6C-5S8XH51-T003

M6C Flameproof Explosion Protected Encoder, ATEX/IECEx Zone 1

Hollow Shaft Bore Size : 5 – 1-1/8 inch Hollow Shaft

Mounting : S – Standard End-of-Shaft Mounting

Line Driver : 8 – 5-24V In/Out Protected Line Driver

Left Output : X – No Left Output

Right Output : H – High Res.

Base PPR : 51 – 512 PPR

Marker : – – No Marker

Connector Options: T – Terminal Block

Modifications : 003 – Includes B28390 Torque Arm Kit

**Replacement for the obsolete M6-5S3XH51-T003…..Please confirm before ordering…”

6.  Code: M6C-4S1HX51-W003

M6C Flameproof Explosion Protected Encoder, ATEX/IECEx Zone 1

Hollow Shaft Bore Size : 4 – 1 inch Hollow Shaft

Mounting : S – Standard End-of-Shaft Mounting

Line Driver : 8 – 5-24V In/Out Protected Line Driver

Left Output : H – High Res.

Right Output : X – No Right Output

Base PPR: 51 – 512 PPR

Marker :  – – No Marker

Connector Options : W – Terminal with Cable Gland

Modifications:  003 – Includes B28390 Torque Arm Kit

M6C-4S1HX51-W003 Replaces the obsolete M6-4S1HX51-W003 ”

7.  Code: HS35MYX6CPU1HA00

HS35M Hollow Shaft Magnetic Mill Duty Encoder

Left Output PPR

Y – 1024 PPR

Right Output PPR

X – No Right Output

Line Driver

6 – 5-24v In/Out (7272)

Hollow Shaft Bore Size

C – 5/8 in. via insert

Connector Options

P – 10 Pin Mini-Epic Style with Plug

Mounting

U – Universal (Thru & End of Shaft)

Protection

1 – Protective Basket Included

Anti-Rotational Tether

H – A and F Tether Kits

Channels and Modifications

A00 – Standard, No Special Features, All Channels A, A\, B, B\, Z, Z\

HS35MYX6CPU1HA00 Replaces part number HS35MYX6HPU1HA00 ”

8.  Code: AV6AS4B23QA2A000

AV6A Solid Shaft Optical Light Mill Duty Absolute Encoder

Communication Bus

S – SSI Communication

Flange

4 – 2.5 in. Square flange, 1.25 in. male pilot

Shaft Size

B – 3/8 inch x 5/8 inch long Solid Shaft, w/flat (flange #4 only)

Turns/bits/MT

2 – 4096 Turns/12 bits

CPR/bits Per Turn/ST

3 – 8192 Counts per Revolution/13 bits

Connector

Q – M23/12 pin w/o Plug, Kubler Pin Out

Connector Exit

A – Side/Radial exit

Output Coding

2 – Gray Coding

IP Rating

A – IP65 Shaft Seals

Modifications

000 – No Special Features ”

9.  Code: M6C-5S8XH51-T005

M6C Flameproof Explosion Protected Encoder, ATEX/IECEx Zone 1

Hollow Shaft Bore Size : 5 – 1-1/8 inch Hollow Shaft

Mounting : S – Standard End-of-Shaft Mounting

Line Driver : 8 – 5-24V In/Out Protected Line Driver

Left Output : X – No Left Output

Right Output : H – High Res.

Base PPR : 51 – 512 PPR

Marker : – – No Marker

Connector Options: T – Terminal Block

Modifications : 005 – -40C Tested Unit with Torque Arm Kit Included ”

10.  Code: M6C-4S8HX51-W003

DESCRIPTION: M6C Flameproof Explosion Protected Encoder, ATEX/IECEx Zone 1

Hollow Shaft Bore Size: 4 – 1 inch Hollow Shaft

Mounting: S – Standard End-of-Shaft Mounting

Line Driver: 8 – 5-24V In/Out Protected Line Driver

Left Output: H – High Res

Right Output: X – No Right Output

Base PPR : 51 – 512 PPR

Marker: – – No Marker

Connector Options: W – Terminal with Cable Gland

Modifications: 003 – Includes B28390 Torque Arm Kit ”

11.  Code: HS35MYX8FPU1CA00

HS35M Hollow Shaft Magnetic Mill Duty Encoder

Left Output PPR : Y – 1024 PPR

Right Output PPR : X – No Right Output

Line Driver : 8 – 5-24v In/Out (HX)

Hollow Shaft Bore Size : F – 1 in. (Native Bore)

Connector Options : P – 10 Pin Mini-Epic Style with Plug

Mounting: U – Universal (Thru & End of Shaft)

Protection: 1 – Protective Basket Included Anti-Rotational Tether: C – 0.375 16 T-Bolt Fan Cover Tether

Channels and Modifications: A00 – Standard, No Special Features, All Channels A, A\, B, B\, Z, Z\ ”

12.  Code: HS35MYX6FCU0XA00

HS35M Hollow Shaft Magnetic Mill Duty Encoder  Left Output PPR

Y – 1024 PPR

Right Output PPR

X – No Right Output

Line Driver

6 – 5-24v In/Out (7272)

Hollow Shaft Bore Size

F – 1 in. (Native Bore)

Connector Options

C – 10 Pin MS Style with Plug, Avtron/BEI Phasing

Mounting

U – Universal (Thru & End of Shaft)

Protection

0 – No Protective Basket

Anti-Rotational Tether

X – No Tether Hardware

Channels and Modifications

A00 – Standard, No Special Features, All Channels A, A\, B, B\, Z, Z\ ”
